6803-2RS ABEC-3 Deep Groove Ball Bearing 17*26*5mm SUNBEARING

6803-2RS ABEC-3 Deep Groove Ball Bearing 17*26*5mm SUNBEARING
6803-2RS ABEC-3 Deep Groove Ball Bearing 17*26*5mm SUNBEARING6803-2RS ABEC-3 Deep Groove Ball Bearing 17*26*5mm SUNBEARING6803-2RS ABEC-3 Deep Groove Ball Bearing 17*26*5mm SUNBEARING6803-2RS ABEC-3 Deep Groove Ball Bearing 17*26*5mm SUNBEARING6803-2RS ABEC-3 Deep Groove Ball Bearing 17*26*5mm SUNBEARING
group name
Deep Groove Ball Bearing
Min Order
1 piece
brand name
SUNBEARING Rolling Bearing Manufacturer
model
6803
Nearest port for product export
Dalian
Delivery clauses under the trade mode
FOB, CFR, CIF, DDP
Acceptable payment methods
T/T, L/C, PayPal, Westem Union
update time
Wed, 26 Oct 2022 16:53:33 GMT

Paramtents

  • Color Silver

  • Inner Diameter 17mm

  • Outer Diameter 26mm

  • Width 5mm

Packging & Delivery

  • Min Order1 piece

Briefing

Widely used to made plastic roller for sliding door and window, we provide these rollers.

Detailed

6803-2RS ABEC-3 Deep Groove Ball Bearing 17*26*5mm

6803 bearing

Product Specification

Bore diameter:17 mmMax Speed (Grease)26,000rpm
Outside diameter: 26 mmMax Speed (Oil)30,000rpm
Overall width:5 mmCage material:Steel
Ball Qty16Bearing material:Steel
Outer ring type:SplitCage type:Inner Ring Guided
Internal clearance:C3Precision rating:A1
Closure type:2-RSWeight:8.2g
Bearing type:Radial BearingMax. Shaft Shoulder Dia. Inner (Li)20 mm
Dynamic load capacity:2,233 NMin. Housing Shoulder Dia., Outer (Lo)23 mm
Static load capacity:1,456 NBall Dia (Dw)2.381 mm

6803 Deep Groove Ball Bearing Technical Specifications

  • Quantity: 1
  • Condition: New Inventory From Factory.
  • Quality Level ABEC 3 or Better
  • Operating  Temperature: Sealed or Metal Shields Ranges: –20 °F to +230°F [–30 °C to +110°C]. The determining factor will be the lube and the seal material.
  • Raceways: Finely polished superior finish for long life, and low noise.
  • Lubrication   Wide temperature range (-50F to + 300F) High-Quality Synthetic Lubricant.

Description

This 6803-2RS 17x26x5-millimeter sealed ball bearing is a single-row bearing for supporting typical radial loads. Its stainless steel construction makes it resistant to corrosion and high temperatures and it conforms to ABEC 3 precision standard for performance within a narrow range of variation. The rubber seals on both sides of the bearing keep lubricant in and contaminants out.

Rolling bearings use rolling elements to maintain the separation between moving parts to reduce rotational friction and support radial and axial loads. These elements can be one of the following types: ball, cylindrical, spherical, barrel, needle, spindle, or tapered. All rolling bearings are open, shielded, or sealed. Sealed bearings are lubricated with oil or grease in the bearing factory, while open and shielded bearings are meant to be lubricated in place, with periodic reapplication of lubrication, based on use. The shield protects the working parts of the bearing from environmental debris that may be introduced and could reduce the ball bearing speed and lifespan. Rolling bearings are used in a range of applications from agricultural machinery to conveying equipment, robotics, dental equipment, elevators, rolling mills, ship rudder shafts, and aggregate crushers, among others.

Application

deep groove ball bearing application

This single-row sealed ball bearing is for use in applications that involve combined radial and axial loads and a need for high running accuracy at high rotational speeds. Such applications include clutches, drives, gearboxes, compressors, pumps, turbines, and printing and textile machines, among others.
